Advantages:
* 5500mW high power, maintains sufficient power output, suitable for long range and ultra-long-distance flights.
* 5 power levels are adjustable: PIT/25mW/1000mW/2000mW/3000mW/5500mW.
* CNC integrated upper and lower shell covering structure, combined with cooling fan, it has a strong heat dissipation effect and maintains stable performance.
* Three-function buttons, parameter adjustment is simpler, with 3 sets of LED indicators to display power/frequency group/frequency point at a glance.
* Onboard microphone for VTX, the sound of the aircraft is transmitted to the ground in real time
* You can directly input any frequency point within 4.9-5.8G, personalized customization of your flight experience.
* Support TBS SmartAudio protocol OSD parameter adjustment.
* Support 2-8s (7-36V) wide voltage input.
* Installation hole: 20*20*M2
Product name: 5.8G 5.5W VTX
Support voltage: DC 7-36V (2-8S)
Antenna interface: SMA
Cable interface: GH1.25 6P
Video format: PAL/NTSC
Standard 64 channels: A/B/E/F/R/O/L/X frequency group
Protocol: TBS SmarAudio
Output power: PIT/25mW/1000mW/2000mW/3000mW/5500mW
PitMode/0dbm
25mW/13.95dBm
1000mW/30.00 dBm
2000mW/33.01 dBm
3000mW/34.77 dBm
5500mW/37.40 dBm
Installation hole: 20*20*M2
Dimensions (L*W*H): 80.33mmx36.06mmx18.37mm
Weight: 68.6g
Shipping List:
1 x 5.8G 5.5W VTX
1 x RG316 SMA to SMA 100mm adapter
1 x GH1.25 6Pin 100mm single-ended cable
1 x SH1.0 4Pin-GH1.25 6Pin 60mm double-ended cable
